Hi-Therm PP-R socket-spigot elbow 90° changes the route direction in PP-R piping with internal/external socket geometry.
Hi-Therm PP-R socket-spigot elbow 90° - changes the route direction in PP-R piping with internal/external socket geometry.
| Parameter | Value |
|---|---|
| Product type | PP-R socket-spigot elbow 90° |
| Material | PP-R |
| Size / diameter | 20 90°, 25 90°, 32 90° mm |
| System use | joint, turn, branch or transition in PP-R pressure piping |
| Construction | one-piece PP-R moulded fitting |
| Working medium | cold water, hot water and water-based heating medium |
| Application | changes the route direction in PP-R piping with internal/external socket geometry. |
| Connection / installation | socket fusion welding with PP-R pipe |
| Standards | EN ISO 15874, DIN 8077/8078, DIN 16962, DVS 2207/2208 |
| Warranty | 10 years |
| Ø (D×D1) [mm] | A [mm] | B [mm] | A1 [mm] | B1 [mm] | Weight [kg] | Package I [pcs] | Package II [pcs] | Article |
|---|---|---|---|---|---|---|---|---|
| 20 90° | 14,5 | 25,5 | 14,5 | 30,0 | 0,015 | 50 | 400 | H11402090 |
| 25 90° | 16,0 | 29,5 | 16,0 | 35,0 | 0,027 | 20 | 200 | H11402590 |
| 32 90° | 18,1 | 35,1 | 18,0 | 41,5 | 0,050 | 10 | 100 | H11403290 |
I and II indicate packaging levels.
Use compatible Hi-Therm PP-R components and installation parameters suitable for the selected diameter. Final system limits are defined by the pipe, fitting, operating temperature and project pressure.
